Zentec Motor
Zentec Motor
| MODEL | VOLTAGE | NO LOAD | AT MAXIMUM EFFICIENCY | STALL | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| OPERATING RANGE | NOMINAL | SPEED | CURRENT | SPEED | CURRENT | TORQUE | OUTPUT | TORQUE | CURRENT | ||||
| V | r/min | A | r/min | A | mN.m | g.cm | w | mN.m | g.cm | A | |||
| TRS-550PM | 35100 | 3.0-18.0 | 12.0 | 5200 | 0.25 | 4330 | 1.60 | 29.41 | 300 | 13.3 | 176.47 | 1800 | 8.32 |
| 6530 | 6.0-12.0 | 12.0 | 18000 | 1.30 | 16100 | 7.15 | 41.18 | 420 | 69.0 | 344.31 | 3512 | 52.0 | |
This motor is widely used in high-performance equipment and consumer goods such as ride-on toys, grass trimmers, portable air compressors, and drills.
Depending on the model configuration, the operating voltage range spans from 3.0V to 18.0V. The TRS-550PM-35100 operates between 3.0-18.0V, while the TRS-550PM-6530 runs on 6.0-12.0V.
Under maximum efficiency, the 35100 variant operates at 4330 r/min with 1.60A current and 300g.cm torque, while the 6530 variant reaches 16100 r/min with 7.15A current and 420g.cm torque.
The motor is engineered with balanced rotors, precision windings, and quality brushes, ensuring low current draw, minimal electromagnetic interference (no sparks), and smooth operation.
The stall torque for the 35100 model is 1800 g.cm at 8.32A, and for the 6530 model, it peaks at 3512 g.cm at 52.0A.
